Suzuki SP250 (1983) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP,THROTTLE This part replaces 57110-37200.

57110-37201

$26.30

2

CASE ASSY, THROTTLE | Includes Item(s) 3

57100-37400

$94.55

3

SCREW This part replaces 02112-05208.

02112-05207

$1.97

4

LEVER ASSY, BRAKE | Includes Item(s) 5 - 11 This part replaces 57300-38220.

57300-11900

Unavailable

5

LEVER, BRAKE

57420-26400

Unavailable

6

BOLT This part replaces 57431-11011.

57431-11013

$6.31

7

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

8

SCREW This part replaces 02112-06208.

02112-06207

$1.78

9

ADJUSTER, CABLE

57441-11010

$5.62

10

NUT

57442-11010

$2.79

11

SWITCH ASSY, STOP This part replaces 57470-10400.

57460-10400

$37.53

12

NO DESCRIPTION AVAILABLE This part replaces 57341-25601.

57341-25602

Unavailable

13

BAND (L:120)

09407-12402

$3.04
