Honda S65A MOTORCYCLE, JPN, VIN# S65-A000001 FRONT FORK Diagram

#

Description
Price

1

ARM, R. FR. SUSPENSION (NOT AVAILABLE)

51210-011-010

Unavailable

2

ARM, L. PIVOT SUSPENSION

51220-001-000

Unavailable

3

STOPPER, FR. ARM REBOUND (NOT AVAILABLE)

51251-001-000

Unavailable

4

BUSHING, FR. FORK (LOWER) (NOT AVAILABLE)

51311-001-000

$11.43

5

BUSHING, FR. ARM PIVOT (NOT AVAILABLE)

51312-001-000

Unavailable

6

COLLAR, FR. ARM PIVOT (NOT AVAILABLE)

51331-001-000

Unavailable

7

DUST SEAL, FR. ARM PIVOT

51332-001-000

Unavailable

8

CAP, FR. ARM PIVOT DUST SEAL

51333-001-000

Unavailable

9

COLLAR, FR. FORK DISTANCE (LOWER) (NOT AVAILABLE)

51334-001-000

Unavailable

10

DUST SEAL, FR. FORK (LOWER)

51335-001-000

$2.11

11

CAP, FR. FORK DUST SEAL (LOWER)

51336-001-000

$2.20

12

SHOCK ABSORBER ASSY., FR. (NOT AVAILABLE)

51400-035-000

Unavailable

13

SPRING, FR. FORK (NOT AVAILABLE)

51401-035-000

Unavailable

14

SEAT, FR. FORK SPRING

51407-001-000

Unavailable

15

GUIDE, FR. FORK SPRING (NOT AVAILABLE)

51409-001-020

Unavailable

16

METAL, FR. FORK (UPPER)

51410-001-040

Unavailable

17

METAL, FR. DAMPER (LOWER) (NOT AVAILABLE)

51420-001-020

Unavailable

18

RUBBER, FR. FORK STOPPER

51475-001-010

Unavailable

19

NUT, FR. FORK LOCK (LOWER)

51482-001-020

Unavailable

20

COLLAR, FR. FORK (OUTER)

51486-035-000

Unavailable

21

COLLAR, FR. FORK (UPPER) (NOT AVAILABLE)

51488-001-000

Unavailable

22

BUSH, FR. FORK (NOT AVAILABLE)

51489-001-000

Unavailable

23

METAL, FR. FENDER FIXING (UPPER) (NOT AVAILABLE)

61117-001-010

Unavailable

24

METAL, FR. FENDER FIXING (LOWER) This part replaces 61142-001-000.

61142-001-010

$3.03

24

METAL, FR. FENDER FIXING (LOWER)

61142-001-010

$3.03

25

BOLT, FR. ARM (NOT AVAILABLE)

90125-001-000

Unavailable

26

BOLT, FR. SHOCK (UPPER) (NOT AVAILABLE)

90147-001-000

Unavailable

27

BOLT, FR. SHOCK ABSORBER (LOWER) (NOT AVAILABLE)

90149-001-000

Unavailable

28

NUT, SELF-LOCK (8MM)

90349-001-000

$2.83

29

BOLT, HEX. (8X50) This part replaces 92000-08050.

92101-08050-0A

$1.97

29

BOLT, HEX. (8X50) This part replaces 92000-08050-0A.

92101-08050-0A

$1.97

29

BOLT, HEX. (8X50)

92101-08050-0A

$1.97

30

NUT, HEX. (8MM) This part replaces 94002-08000.

94031-08000

$1.49

30

NUT, HEX. (8MM)

94031-08000

$1.49

31

NUT, CAP (8MM) This part replaces 94021-08020.

94021-08020-0S

$1.82

31

NUT, CAP (8MM)

94021-08020-0S

$1.82

31

NUT, CAP (8MM) This part replaces 94021-08060-0S.

94021-08020-0S

$1.82

31

NUT, CAP (8MM) This part replaces 94021-08090-0S.

94021-08020-0S

$1.82

31

NUT, CAP (8MM) This part replaces 94022-08020-0S.

94021-08020-0S

$1.82

32

WASHER, SPRING (8MM)

94111-08000

$1.49

33

FITTING, GREASE (A.45) This part replaces 96201-30000.

96201-30001

$1.49

33

FITTING, GREASE (A.45)

96201-30001

$1.49
