Yamaha RX10PBL (APEX) 8HG20 2012 STEERING GATE Diagram

#

Description
Price

1

STEERING GATE COMP.

8HG-23870-02-00

Unavailable

2

STOPPER

8HG-23376-00-00

$10.32

3

STOPPER

8FA-24768-00-00

Unavailable

4

WASHER, PLATE

90201-10032-00

$1.02

5

COVER, MOTOR

8HG-238B6-01-00

$25.11

6

BOLT, WITH HOLE

90102-08007-00

Unavailable

7

BOLT(3KJ)

90109-063F1-00

$2.15

8

BRACKET

JT1-83614-00-00

$20.45

9

SCREW, BIND (705)

98980-06016-00

$6.35

10

WASHER, PLATE(49E)

90201-087H6-00

$1.51

11

NUT,FLANGE(J10)

95702-08500-00

$0.79

12

BOLT, FLANGE

90105-08236-00

$3.48

13

WASHER (853)

90201-08326-00

$5.75

14

BOLT, FLANGE(6TA)

95817-08030-00

$5.75

15

LATCH

8FA-2389E-00-00

$10.30

16

NUT, SELF-LOCKING

95602-08200-00

Unavailable

17

CLAMP

90462-10022-00

Unavailable

18

CLIP 136253750000

90468-12006-00

Unavailable
