Suzuki RM85 (2008) REAR WHEEL (RM85LK7/LK8) Diagram

#

Description
Price

1

HUB, REAR WHEEL

64111-02B43

$322.15

2

SPACER, BEARING (15.3X21.7X97)

64731-02B40

$27.55

3

BEARING, RH

08123-60027

$25.32

4

BEARING, LH (15X35X11)

09262-15021

$23.75

5

CIRCLIP, LH

08331-41359

$2.28

6

SEAL, DUST (20X35X7)

09283-20024

$4.68

7

DISC, REAR BRAKE

69211-03B00

$224.25

8

SCREW

02122-0612B

$1.86

9

BRACKET, CALIPER

69721-03B10

$193.63

10

AXLE, REAR

64711-03B70

$33.97

11

SPACER, AXLE

64741-03B80

$29.78

12

WASHER (14.5X30X3.2) This part replaces 09160-14033.

09160-14062

$2.79

13

NUT

08319-3114A

$8.84

14

SPROCKET, REAR (NT:47)

64511-03B00

$141.76

14

SPROCKET, REAR (NT:46) | OPT

64511-03B10

$147.17

14

SPROCKET, REAR (NT:48) | OPT

64511-03B20

$147.17

14

SPROCKET, REAR (NT:49) | OPT

64511-03B30

Unavailable

15

SCREW (8X30.5)

09120-08010

$2.39

16

NUT

09159-08067

$5.03

17

RIM, WHEEL (1.60X16)

65311-03B60

Unavailable

18

SPOKE ASSY, WHEEL

65320-03B60

$83.83

19

TIRE, REAR (90/100-16 52M D737)(DUNLOP)

65110-03BA0

Unavailable

20

TUBE ASSY, INNER

65200-03B90

$52.72

21

PROTECTOR, INNER TUBE This part replaces 65261-03B80.

65261-03B50

$9.25

22

STOPPER, BEAD

65270-43D00

$66.32

23

WASHER

08322-0108B

$2.37

24

NUT

08310-0008B

$2.95
