Suzuki RM125 (2006) STAND - FOOTREST (MODEL K3/K4/K5) Diagram

STAND, PROP

42310-36E40

Unavailable

FOOTREST, RH (BLACK) | MODEL K3/K4

43551-36F00-019

Unavailable

FOOTREST, RH (BLACK) | MODEL K5/K6

43551-37F01-019

$161.72

FOOTREST, LH (BLACK) | MODEL K3/K4

43561-36F00-019

Unavailable

FOOTREST, LH (BLACK) | MODEL K5/K6

43561-37F00-019

$161.72

PIN

09200-10022

$9.30

CITTER PIN This part replaces 04111-25208.

04111-2520A

$1.22

SPRING, RH

09448-21008

$7.50

SPRING, LH

09448-21007

$7.47

WASHER, KNUCKLE END This part replaces 08322-01103.

08322-0110A

$1.83
