Suzuki RM125 (1988) FRONT CALIPER (MODEL G) Diagram

#

Description
Price

NO DESCRIPTION AVAILABLE | Includes Item(s) 1 - 16 This part replaces 59300-14600.

59300-14510

Unavailable

1

PISTON SET

59300-14820

Unavailable

2

..SEAL SET,PISTON This part replaces 59107-14500.

69100-04820

$8.27

3

DUST SEAL

59108-14500

Unavailable

4

PAD SET This part replaces 59340-14600.

59300-14840

Unavailable

5

SPRING

59315-14600

$13.35

6

SHIM

59371-14500

Unavailable

7

BOOT

59386-13A00

$7.28

8

BOLT

59382-14500

$8.43

9

BOOT

59303-14500

$5.06

10

BOLT

59305-14500

$26.03

11

NUT

59306-14500

Unavailable

12

PIN

59345-14600

$18.33

13

BRACKET

59351-14600

Unavailable

14

RETAINER

59316-14600

Unavailable

15

BLEEDER

59121-01A00

$7.99

16

CAP

59122-01A00

$3.97

17

BOLT (8X29) This part replaces 09103-08156.

09103-08409

$3.82
