1985 Suzuki RM125 Right Handle Switch Diagram

← All diagrams

Find the part on the Right Handle Switch diagram for your 1985 Suzuki RM125, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1985 Suzuki RM125 Right Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, THROTTLE This part replaces 57110-14300.

57110-27C00

1
Out of stock

2

ROTOR, THROTTLE

57114-20410

1
Out of stock

3

CASE ASSY, THROTTLE | Includes Item(s) 4 - 7

57100-20411

1
Out of stock

4

GUIDE PIECE

57122-20410

1
Out of stock

5

COVER

57129-20411

1
Out of stock

6

SCREW This part replaces 02132-04068.

02122-0410A

1
Out of stock

7

SCREW This part replaces 02112-05168.

02112-05167

2
Out of stock

8

LEVER, BRAKE This part replaces 57421-14500.

57421-14502

1
Out of stock

9

BOLT, BRAKE LEVER

57431-14500

1
Out of stock

10

NUT This part replaces 57442-14500.

08316-1006B

1
Out of stock

11

BOLT, ADJUST This part replaces 57431-14510.

57431-14511

1
Out of stock

12

NUT This part replaces 08310-12055.

08310-0005A

1
Out of stock

13

SPRING, RETURN This part replaces 57318-14500.

57318-14502

1
Out of stock

14

COVER, BRAKE LEVER This part replaces 57341-14500.

57341-14501

1
Out of stock

15

COVER, THROTTLE CASE

57129-14501

1
Out of stock
