Suzuki RM125 (1985) LEFT HANDLE SWITCH (MODEL E) Diagram

#

Description

Price

1

GRIP LH This part replaces 57211-40201.

57211-27C00

$11.25

2

LEVER ASSY, CLUTCH | Includes Item(s) 3 - 9

57500-14300

Unavailable

3

LEVER, CLUTCH

57620-14300

$18.53

4

BOLT This part replaces 57431-14300.

57431-14301

$6.05

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.89

6

ADJUSTER, CABLE

57441-14210

$11.20

7

NUT

57442-14200

$6.32

8

HOLDER

57512-14300

$46.20

9

SCREW This part replaces 02112-05168.

02112-05167

$1.97

10

COVER, CLUTCH LEVER This part replaces 57341-40001.

57341-40003

$5.02
