- PZ50RTEW (PHAZER RTX) 8GNF 2014
ELECTRICAL 1
2014 Yamaha Phazer RTX (PZ50RTEW) Electrical 1 Diagram
Find the part on the Electrical 1 diagram for your 2014 Yamaha Phazer RTX (PZ50RTEW), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
Description
Qty in Assembly
Price
Status
Order Qty
2
BAND, BATTERY
2T4-82131-00-00
1
Out of stock
5
SENSOR, CAM POSITION
8GC-85896-02-00
1
Out of stock
34
SENSOR, PRESSURE
5PS-82380-00-00
—
Out of stock
More Electrical diagrams
