1983 Yamaha PW80 (PW80K) Shift CAM - Fork Diagram

← All diagrams

Find the part on the Shift CAM - Fork diagram for your 1983 Yamaha PW80 (PW80K), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1983 Yamaha PW80 (PW80K) Shift CAM - Fork Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

SHIFT CAM ASSY

21W-18540-01-00

—
Out of stock

2

PIN,DOWEL (620)

93604-22050-00

1

$6.68

In stock

3

PLATE, SIDE

296-18561-00-00

1

$5.38

In stock

4

CIRCLIP(J51)

99080-09600-00

1

$1.88

In stock

5

BRG,CYL-CAL ROLLER 18G KY

93315-23208-00

1

$29.23

In stock

6

PLATE, STOPPER

296-18562-01-00

1
Out of stock

7

SCREW, PAN

98507-06014-00

1

$6.18

In stock

8

FORK, SHIFT 1

58H-18511-00-00

1
Out of stock

9

FORK, SHIFT 2

58H-18512-00-00

1
Out of stock

10

PIN,DOWEL(296)

93606-14081-00

1
Out of stock

11

BAR SHIFT FORK GUIDE

2N8-18531-00-00

—
Out of stock

12

CIRCLIP

99006-10600-00

1

$6.91

In stock

13

O-RING

93210-08003-00

1

$6.86

In stock

14

STOPPER LEVER ASSY

296-18140-03-00

—
Out of stock

15

BOLT

90109-06239-00

1

$5.77

In stock

16

SPRING, TENSION

90506-10006-00

—
Out of stock

17

HOOK, SPRING

132-16346-00-00

—
Out of stock
