1983 Kawasaki Prairie Clutch Diagram

← All diagrams

Find the part on the Clutch diagram for your 1983 Kawasaki Prairie, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1983 Kawasaki Prairie Clutch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

BRACKET,CLUTCH CABLE

11045-1081

1
Out of stock

2

CLUTCH-ASSY

13081-1068

1
Out of stock

3

HUB,CLUTCH

13087-1001

1

$110.74

In stock

4

PLATE,CLUTCH FRICTION

13088-1008

1
Out of stock

5

PLATE-CLUTCH,T=1.6

13089-013

1

$10.41

In stock

6

HOUSING,CLUTCH

13095-1015

1
Out of stock

7

RELEASE,CLUTCH

13102-1011

1
Out of stock

8

PLATE-CLUTCH OPERATING

13187-1008

1
Out of stock

9

ROD,CLUTCH PUSH

46102-1033

1
Out of stock

10

BOLT,CLUTCH SPRING,6X18

92001-1576

1
Out of stock

11

1

$12.85

In stock

12

SPRING,CLUTCH

92081-083

1

$6.77

In stock

13

O RING,9MM

670B1509

1

$2.92

In stock
← Chain Case Gear Change Drum & Forks →

More Drive & Transmission diagrams
