- Outlander 400, 2003
05- CVT / Transmission
Can-Am Outlander 400, 2003 05- CVT / Transmission Diagram
#
1
Allen Screw M6 x 30,5
420440561
Unavailable
2
CVT COVER - Call your local BRP dealership
420610420
Unavailable
3
CVT Cover Gasket
420630290
Unavailable
4
Hex. Screw M12 X 140
420641812
Unavailable
5
Spring Washer
420627760
Unavailable
6
CVT Drive Ass'y | 400HO / Includes 6 to 24
420684400
Unavailable
6
Governor Cup Ass'y | Includes 6 to 9
420280522
Unavailable
6
Not Available As Spare Part - Friction Washer
Unavailable
7
Slider Shoe Set
420281296
Unavailable
8
Roller Axle
417223257
Unavailable
9
Roller
417223767
Unavailable
10
Outer Half Ass'y | 400HO / Includes 10 to 16
420280310
Unavailable
10
Not Available As Spare Part - Friction Washer
Unavailable
11
Not Available As Spare Part - Friction Washer
Unavailable
12
Not Available As Spare Part - Friction Washer
Unavailable
13
Not Available As Spare Part - Friction Washer
Unavailable
14
Centrifugal Lever Set | 400HO / Includes 14 to 16
420248424
Unavailable
14
Not Available As Spare Part - Friction Washer
Unavailable
15
Not Available As Spare Part - Friction Washer
Unavailable
16
Not Available As Spare Part - Friction Washer
Unavailable
17
Compression Spring
420238166
Unavailable
18
Seat Spring
420627578
Unavailable
19
Clutch
420257439
Unavailable
20
Ball Bearing
420632377
Unavailable
21
Retaining Ring
420245951
Unavailable
22
Inner half ass'y
420280245
Unavailable
23
Spring Sleeve
420229577
Unavailable
24
COMPRESSION SPRING - Call your local BRP dealership
420239131
Unavailable
25
Hex. Screw M10 X 110
420441485
Unavailable
26
Thrust Washer
420627590
Unavailable
27
CVT Driven Pulley Ass'y | Includes 27 to 40
420684450
Unavailable
27
Outer Half Pulley Ass'y | Includes 27 to 32
420280178
Unavailable
27
Not Available As Spare Part - Friction Washer
Unavailable
28
Ball Bearing
420932421
Unavailable
29
Not Available As Spare Part - Friction Washer
Unavailable
30
Not Available As Spare Part - Friction Washer
Unavailable
31
TORQUE GEAR - Call your local BRP dealership
420660120
Unavailable
32
Retaining Ring
420245911
Unavailable
33
Inner Half Ass'y | Includes 33 to 35
420248233
Unavailable
33
Not Available As Spare Part - Friction Washer
Unavailable
34
Not Available As Spare Part - Friction Washer
Unavailable
35
Not Available As Spare Part - Friction Washer
Unavailable
36
Compression Spring
420238340
Unavailable
37
Driven Pulley Shaft
420220913
Unavailable
38
Cam
420280250
Unavailable
39
Cam Plate
420627586
Unavailable
40
Drive Belt
422280283
Unavailable
41
Thrust Washer
420627920
Unavailable
42
LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership
219704461
Unavailable
