2024 Kawasaki Ninja ZX-4RR Fuel Injection Diagram

← All diagrams

Find the part on the Fuel Injection diagram for your 2024 Kawasaki Ninja ZX-4RR, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2024 Kawasaki Ninja ZX-4RR Fuel Injection Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

21175

1

$1,134.05

In stock

21176

SENSOR,WATER TEMP

21176-0009

1

$63.44

In stock

21176A

1

$24.07

In stock

21176B

SENSOR,VEHICLE-DOWN

21176-0704

1

$84.36

In stock

21176C

1

$145.08

In stock

21176D

SENSOR,OXYGEN

21176-0931

1

$290.02

In stock

92055

RING-O,9.5X1.9

92055-0016

1
Out of stock

92055A

RING-O

92055-0917

1

$3.27

In stock

92154

BOLT

92154-3764

1

$1.47

In stock

92161

DAMPER

92161-0951

1

$14.14

In stock

92161A

DAMPER,ECU

92161-2487

1

$22.60

In stock

92172

SCREW,TAPPING,5X16

92172-0790

1

$0.85

In stock

411

WASHER-PLAIN,6MM

411AA0600

1

$2.39

In stock
