Find the part on the Radiator diagram for your 2026 Kawasaki Mule PRO-FXT™ 1000 LE, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2026 Kawasaki Mule PRO-FXT™ 1000 LE Radiator Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11009

GASKET,RESERVOIR TANK CAP

11009-1145

1
Out of stock

11012

CAP

11012-1084

1
Out of stock

11056

BRACKET,RESERVOIR

11056-3856

1
Out of stock

11057

BRACKET,RADIATOR

11057-0774

1
Out of stock

11058

BRACKET

11058-0325

1
Out of stock

13280

HOLDER,BREAKER

13280-0898

1

$1.71

In stock

14093

COVER,RADIATOR BACK

14093-1391

1
Out of stock

16160

BODY,THERMOSTAT COVER

16160-0839

1
Out of stock

16160A

BODY,THERMOSTAT

16160-0840

1
Out of stock

21008

BREAKER,RAD.FAN,20A

21008-0015

1
Out of stock

39060

RADIATOR

39060-0753

1
Out of stock

39062

1

$86.65

In stock

39062A

1

$5.61

In stock

39062B

1

$66.42

In stock

39062C

HOSE-COOLING,RAD-RESERVOIR

39062-0985

1
Out of stock

39062D

HOSE-COOLING,ENGINE IN

39062-0986

1
Out of stock

39062E

HOSE-COOLING,W/PUMP-ENGINE

39062-0987

1
Out of stock

39062F

HOSE-COOLING,ENGINE OUT

39062-0988

1
Out of stock

39192

PIPE-WATER,RH

39192-0574

1

$67.53

In stock

39192A

PIPE-WATER,LH

39192-0715

1
Out of stock

43078

RESERVOIR

43078-0571

1
Out of stock

49054

THERMOSTAT

49054-0015

1
Out of stock

49085

CAP-ASSY-PRESSURE

49085-0019

1
Out of stock

59502

FAN-ASSY

59502-0641

1
Out of stock

92005

FITTING

92005-1445

1
Out of stock

92022

WASHER,PLAIN,6.5X20X1

92022-165

1
Out of stock

92022A

WASHER,6.2X11X1

92022-304

1
Out of stock

92027

COLLAR,L=4.6

92027-1168

1
Out of stock

92037

CLAMP,TUBE

92037-1461

1
Out of stock

92055

RING-O,YP 27.6 57.6 1.9

92055-0021

1
Out of stock

92055A

RING-O,53.5X2.6

92055-0831

1
Out of stock

92055B

RING-O,FITTING

92055-0923

1
Out of stock

92072

BAND,L=123

92072-030

1
Out of stock

92072A

BAND,OS170-FT7(BLACK)

92072-1414

1
Out of stock

92075

DAMPER

92075-1185

1
Out of stock

92152

COLLAR

92152-2844

1
Out of stock

92161

DAMPER

92161-2436

1
Out of stock

92171

CLAMP

92171-0453

1

$3.12

In stock

92172

SCREW,6X16

92172-0284

1
Out of stock

92172A

SCREW,TAPPING,6X16

92172-0739

1
Out of stock

92173

CLAMP

92173-1204

1
Out of stock

92173A

CLAMP,28.6MM

92173-1205

1
Out of stock

92173B

CLAMP,33.4MM

92173-1981

1
Out of stock

130

BOLT-FLANGED,6X10

130BA0610

1

$1.12

In stock

130A

BOLT-FLANGED,6X12

130BA0612

1

$1.46

In stock

130B

BOLT-FLANGED,6X16

130BA0616

1

$1.12

In stock

130C

BOLT-FLANGED,6X25

130BA0625

1

$1.01

In stock

132

1

$2.05

In stock

132A

1

$2.17

In stock
