Kawasaki MULE PRO-DXT™ EPS DIESEL FE Guard(s) Diagram

Description

Price

130

BOLT-FLANGED,6X20

130BA0620

$1.28

13272

PLATE

13272-2323

$203.14

13272A

PLATE

13272-2324

$203.14

13272B

PLATE

13272-2327

$25.53

13272C

PLATE

13272-2328

$25.53

13272D

PLATE,UNDER GUARD,LH

13272-2330

$52.64

13272E

PLATE,UNDER GUARD,RH

13272-2331

$52.64

39184

BRACKET-ASSY,SIDE,LH

39184-0718

$46.87

39184A

BRACKET-ASSY,SIDE,RH

39184-0719

$46.87

92009

SCREW,TAPPING,6X16

92009-1166

$4.18

92015

NUT,RUBBER,6MM

92015-1692

$5.61

92022

WASHER,8.2X19X2

92022-1533

$4.85

92039

RIVET,4.8X7.6

92039-0784

$1.77

92172

SCREW,6X16

92172-0284

$0.90
