Description

Price

1

HUB, REAR WHEEL (GRAY)

64110-07G00-YU8

$276.78

2

RIM, REAR WHEEL (9X8.0AT) This part replaces 65310-07G00.

65310-07G10

Unavailable

3

NUT

09140-10021

$2.01

4

WASHER

09164-20002

$3.33

5

NUT, HUB

09141-20002

$4.62

6

PIN, COTTER This part replaces 04111-40408.

04111-4040A

$1.37

7

AXLE, REAR

64710-07G10

Unavailable

8

NUT, REAR AXLE RH

64871-07G00

$27.00

9

HOUSING, RR AXLE BEARING This part replaces 64715-07G10.

64715-07G20

$309.65

10

SPACER, RR AXLE BEARING

64731-07G00

$64.78

11

BEARING, REAR AXLE

08123-60087

$39.80

12

SEAL, RR AXLE BEARING DUST

09283-50006

$19.74

13

DISC, REAR BRAKE

69211-07G00

$314.15

14

BOLT, DISC

09106-08160

$3.22

15

TIRE, REAR

65110-07G00

$336.21

16

VALVE ASSY, WHEEL RIM (TR412)

43130-24A00

$8.10

Suzuki LT-Z400 (2007) RIGHT REAR WHEEL (MODEL K4) Diagram
