Description

Price

1

HUB, REAR WHEEL (BLACK) | MODEL K5 FOR YU1 MODEL K6/K7

64110-07G10-019

$273.25

1

HUB, REAR WHEEL (BLUE) | MODEL K5 FOR 30H

64110-07G10-YBA

Unavailable

2

RIM, REAR WHEEL (9X8.0AT)

65310-07G10

Unavailable

3

NUT

09159-10114

$4.67

4

WASHER

09164-20002

$3.33

5

NUT, HUB

09141-20002

$4.62

6

PIN, COTTER This part replaces 04111-40408.

04111-4040A

$1.37

7

AXLE, REAR This part replaces 64710-07G21.

64710-07G30

$1,056.30

8

NUT, REAR AXLE RH

64871-07G11

$57.83

9

WASHER, REAR AXLE, R

09164-38001

$4.83

10

HOUSING, RR AXLE BEARING

64715-07G20

$309.65

11

SPACER, RR AXLE BEARING

64731-07G00

$64.78

12

BEARING, REAR AXLE

08123-60087

$39.80

13

SEAL, RR AXLE BEARING DUST

09283-50006

$19.74

14

DISC, REAR BRAKE

69211-07G00

$314.15

15

BOLT, DISC

09106-08160

$3.22

16

TIRE, REAR

65110-07G00

$336.21

17

VALVE ASSY, WHEEL RIM (TR412)

43130-24A00

$8.10

Suzuki LT-Z400 (2007) RIGHT REAR WHEEL (MODEL K5/K6/K7) Diagram
