2025 Kawasaki KX112 Clutch Diagram

← All diagrams

Find the part on the Clutch diagram for your 2025 Kawasaki KX112, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki KX112 Clutch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13087

HUB-CLUTCH

13087-1170

1

$61.36

In stock

13088

PLATE-FRICTION

13088-1016

1

$11.01

In stock

13089

PLATE-CLUTCH

13089-1120

1

$6.62

In stock

13095

HOUSING-COMP-CLUTCH

13095-1406

1

$250.96

In stock

13187

1

$44.43

In stock

13236

LEVER-COMP,RELEASE

13236-1298

1
Out of stock

46102

ROD,CLUTCH RELEASE

46102-1409

1

$18.91

In stock

92025

SHIM

92025-1780

1
Out of stock

92028

BUSHING,20X25X21.1

92028-1811

1

$13.61

In stock

92046

BEARING-NEEDLE,KT252910EG

92046-1254

1
Out of stock

92081

SPRING,CLUTCH

92081-1492

1

$5.88

In stock

92150

BOLT,6X20,WASHER

92150-1715

1

$3.14

In stock

92200

WASHER,20.3X33X2.0

92200-1351

1
Out of stock

92200A

WASHER,20X30X2.6

92200-1352

1
Out of stock

92210

NUT,16MM

92210-1113

1
Out of stock

601

BEARING-BALL

601A6001

1

$9.26

In stock
