Kawasaki KLX®230 S ABS Chassis Electrical Equipment Diagram

#

Description
Price

11057

BRACKET,FUSE BOX

11057-2350

$2.63

11057A

BRACKET,RR HARNESS

11057-2351

$1.78

11057B

BRACKET

11057-2463

$9.86

11057C

BRACKET,BRAKE HOSE&HARNESS

11057-2772

$8.53

11058

BRACKET

11058-1293

$18.75

11058A

BRACKET

11058-1296

$4.42

11058B

BRACKET

11058-1299

$18.05

14093

COVER,HARNESS

14093-0720

$4.07

21061

RECTIFIER

21061-1003

$30.17

21180

TRANSCEIVER,BLUETOOTH

21180-0007

$179.01

23062

BRACKET-COMP

23062-1511

$20.85

26006

FUSE,MINI BLADE,15A,BLUE

26006-0001

$5.34

26006A

FUSE,MINI BLADE,10A,RED

26006-1078

$3.36

26011

WIRE-LEAD,BATTERY(+)

26011-2455

$61.11

26011A

WIRE-LEAD,BATTERY(-)

26011-2456

$58.85

26011B

WIRE-LEAD,DIAG CONNECTOR

26011-2468

$5.12

26012

BATTERY,YTX7A-BS,12V 6.3AH

26012-0989

$184.23

26031

HARNESS,MAIN

26031-4405

$726.53

26031A

HARNESS,MAIN

26031-4406

$726.53

27002

RELAY-ASSY,TURN SIGNAL

27002-0031

$24.24

27003

HORN

27003-0166

$78.60

27034

RELAY

27034-0012

$37.62

39137

STAY-COMP

39137-0749

$51.11

39156

PAD,55X30X5

39156-2451

$1.68

92072

BAND,L=152

92072-0948

$3.61

92072A

BAND,L=140

92072-0949

$6.10

92072B

BAND,L=250

92072-0950

$1.80

92072C

BAND,OS170-FT7(BLACK)

92072-1414

Unavailable

92154

BOLT,FLANGED,6X12

92154-1776

$0.69

92154A

BOLT,FLANGED,6X12

92154-2776

$2.20

92154B

BOLT,FLANGED,6X10

92154-7280

$1.44

92161

DAMPER

92161-2516

$14.56

92161A

DAMPER,RELAY

92161-2546

$5.08

92171

CLAMP,20MM DIA.

92171-0069

$2.29

92171A

CLAMP

92171-0911

$7.56

92172

SCREW,CROS,5X10

92172-1255

$0.44

92173

CLAMP

92173-2194

$1.56

92173A

CLAMP

92173-2199

$1.32

92173B

CLAMP

92173-2737

$3.39

130

BOLT-FLANGED,6X10

130BA0610

$0.97

130

BOLT-FLANGED,6X10

130BA0610

$0.97
