Find the part on the Cowling diagram for your 2025 Kawasaki KLR650 Adventure ABS, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki KLR650 Adventure ABS Cowling Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11057

BRACKET,WINDSHIELD,LH

11057-4397

1
Out of stock

11057A

BRACKET,WINDSHIELD,RH

11057-4398

1
Out of stock

11057B

BRACKET,DASHBOARD,LH

11057-7243

1
Out of stock

11057C

BRACKET,DASHBOARD,RH

11057-7245

1
Out of stock

11057D

BRACKET,METER

11057-7893

1
Out of stock

14093

COVER,SHROUD,LH

14093-1074

1
Out of stock

14093A

COVER,SHROUD,RH

14093-1075

1
Out of stock

14093B

COVER,DASHBOARD

14093-1076

1
Out of stock

39137

STAY-COMP,COWLING

39137-0731

1
Out of stock

39154

WINDSHIELD

39154-0434

1
Out of stock

39156

PAD,10X50X2

39156-1924

1

$2.02

In stock

39156A

PAD,10X80X2

39156-2238

1
Out of stock

39156B

PAD,25X25X2

39156-2573

1
Out of stock

39156C

PAD,20X15X150

39156-2762

1
Out of stock

39156D

PAD,20X10X2

39156-2849

1
Out of stock

49089B

SHROUD-ENGINE,LH,M.M.T.BLUE

49089-0995-68M

1
Out of stock

49089F

SHROUD-ENGINE,RH,M.M.T.BLUE

49089-0996-68M

1
Out of stock

55028

COWLING,UPP

55028-0800

1
Out of stock

92015

NUT,CAP,8MM

92015-1151

1
Out of stock

92015A

NUT,WELL,5MM

92015-1757

1
Out of stock

92027

COLLAR,L=7.4

92027-1848

1
Out of stock

92039

RIVET

92039-0709

1
Out of stock

92150

BOLT,6X20

92150-1339

1
Out of stock

92152

COLLAR

92152-2770

1
Out of stock

92153

BOLT,6X18

92153-0816

1
Out of stock

92154

BOLT,SOCKET,5X20

92154-0216

1
Out of stock

92154A

BOLT,SOCKET,5X18

92154-1945

1
Out of stock

92154B

BOLT,SOCKET,8X20

92154-2314

1
Out of stock

92154C

BOLT,SOCKET,6X12

92154-2355

1
Out of stock

92160

DAMPER

92160-1613

1
Out of stock

92161

DAMPER,12X23

92161-1367

1
Out of stock

92161A

DAMPER,10X18X6.5

92161-2091

1
Out of stock

92161B

DAMPER,10X20X6

92161-2168

1
Out of stock

92172

SCREW,5X12

92172-0821

1
Out of stock

92200

WASHER,NYLONE,5.3X11.5X0.5

92200-0006

1
Out of stock

92200A

WASHER,5.2X10X1

92200-2286

1
Out of stock

92210

NUT,5MM

92210-0001

1
Out of stock

120

BOLT-SOCKET,5X12

120CB0512

1
Out of stock

130

BOLT-FLANGED,6X12

130BA0612

1

$1.46

In stock

130A

BOLT-FLANGED,8X40

130BA0840

1

$1.68

In stock
