Kawasaki KFX®450R Rear Fender(s) Diagram

Description

Price

35023

FENDER-REAR,OUTER,LH,L.GREEN

35023-0081-290

Unavailable

35023A

FENDER-REAR,OUTER,LH,BLACK

35023-0081-839

$95.15

35023B

FENDER-REAR,OUTER,RH,L.GREEN

35023-0082-290

$79.37

35023C

FENDER-REAR,OUTER,RH,BLACK

35023-0082-839

$95.15

35023D

FENDER-REAR,MAIN,B.WHITE

35023-0113-266

$147.64

35023E

FENDER-REAR,MAIN,L.GREEN

35023-0113-290

$147.64

35063

STAY,REAR FENDER,LH

35063-0290

$21.01

35063A

STAY,REAR FENDER,RH

35063-0291

$21.01

92015

NUT,LOCK,FLANGED,5MM

92015-1752

$3.29

92150

BOLT,6X20

92150-1014

$3.14

92152

COLLAR

92152-0401

$3.12

92172A

SCREW,5MM

92172-0292

$2.34

92210

NUT,WELL,5MM

92210-0370

$4.27

92027

COLLAR

92027-1987

$1.76

92172

SCREW,5MM

92172-0261

$2.34

92172B

SCREW,5X25

92172-0445

Unavailable
