1972 Yamaha JT2_JT2MX (JT2MX) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1972 Yamaha JT2_JT2MX (JT2MX), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1972 Yamaha JT2_JT2MX (JT2MX) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

KICK CRANK ASSY

4BC-15620-00-00

1
Out of stock

2

LEVER, KICK

(214-15612-09-00)

1
Out of stock

3

SPRING,KICK CRANK

214-15625-00-00

1
Out of stock

4

WASHER,SPEC'L SHAPE

90209-10210-00

1
Out of stock

5

. CIRCLIP, OUTER

93440-10028-00

1
Out of stock

6

COVER, KICK LEVER

156-15618-01-00

1

$6.43

In stock

7

BOLT, HEXAGON

97017-06020-00

1

$2.55

In stock

8

KICK AXLE ASSEMBLY

180-15660-01-00

1
Out of stock

9

OIL SEAL (15X26X6-102)

93109-15001-00

1

$7.42

In stock

10

CIRCLIP(1AR)

99009-15400-00

1

$5.10

In stock

11

COVER, KICK SPRING

132-15676-01-00

—

$9.02

In stock

12

SPRING TORSION 304156650000

90508-26136-00

—
Out of stock

13

GUIDE, KICK SPRING

132-15664-01-00

1
Out of stock

14

CIRCLIP (256)

93410-25017-00

1
Out of stock

15

WASHER, PLATE(59W)

90201-253K0-00

1

$6.18

In stock

16

GEAR, KICK

180-15641-00-00

1
Out of stock

17

CLIP 315156870000

90468-26048-00

—
Out of stock

18

STOPPER, KICK SPRING

257-15668-00-00

1
Out of stock
