Sea-doo GTI LE RFI, 2004 Oil System Diagram

#

Description
Price

1

Oil Tank

275000238

Unavailable

2

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

Unavailable

2

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

Unavailable

2

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

3

Filler Hose

275000188

Unavailable

4

Tridon Clamp

293650035

Unavailable

5

FILLER NECK - Call your local BRP dealership

275000242

Unavailable

6

Gasket

293250132

Unavailable

7

Nut-Neck Oil Filler

211100013

Unavailable

8

Oil Cap

275000186

Unavailable

9

Oil Tank Cap

275000199

Unavailable

10

O-RING - Call your local BRP dealership

293250025

Unavailable

11

Oil Cap Chain

275500015

Unavailable

12

Pop Rivet 1/8"

390407900

Unavailable

13

Flat Washer M3, Stainless

234032600

Unavailable

14

OIL LEVER SENSOR ASS'Y - Call your local BRP dealership

278001401

Unavailable

15

Wire Seal

278000218

Unavailable

16

Male Terminal | XT Models

278000222

Unavailable

17

Female Housing, 2 Circuits

278000217

Unavailable

18

Grommet

293720008

Unavailable

19

Was 275500549 Hose 1/4"

219704357

Unavailable

20

Tie Wrap 142 mm

293750002

Unavailable

21

Was 275500008 Hose 12 mm

219704356

Unavailable

22

Norma Clamp

293650084

Unavailable

23

Check Valve

275500398

Unavailable

24

Grommet

293720008

Unavailable

25

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

26

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

Unavailable

27

Tie Wrap 94 mm | 4X4

293750001

Unavailable

28

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

29

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

Unavailable

30

Tie Wrap 94 mm | 4X4

293750001

Unavailable

31

Oetiker Clamp

293650042

Unavailable

32

Was 275500008 Hose 12 mm

219704356

Unavailable

33

Norma Clamp

293650084

Unavailable
