Suzuki GT550 (1972) RH HANDLE SWITCH Diagram

#

Description
Price

1

GRIP ASSY, THROTTLE | Includes Item(s) 2 - 7 This part replaces 57100-34010.

57100-34013

Unavailable

2

GRIP, THROTTLE | FROM 57110-33010

57110-33012

Unavailable

3

BUTTON, STARTING

57370-01311

Unavailable

4

SPRING, STARTING BUTTON

57382-01311

Unavailable

5

ADJUSTER, THROTTLE GRIP

57170-11011

Unavailable

6

NUT This part replaces 08311-11058.

08310-00057

$1.84

7

SCREW This part replaces 02111-05257.

02112-05257

$1.49

8

LEVER ASSY, BRAKE | Includes Item(s) 9 - 20

57300-31010

Unavailable

9

LEVER, BRAKE

57421-31010

Unavailable

10

BOLT, LEVER PLVOT

57431-31010

$9.32

11

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

12

NUT, LEVER PLVOT

57433-11010

$5.64

13

PIN This part replaces 04111-16158.

04111-1620A

$1.49

14

ADJUSTER, CABLE

57441-11010

$5.62

15

NUT, CABLE ADJUSTER

57442-11010

$2.79

16

BOLT | FROM 47451-11010 This part replaces 01112-06208.

01500-06207

$2.28

17

PIECE, BRAKE CABLE END

57452-31010

Unavailable

18

SPACER

57453-31010

Unavailable

19

BOLT

57454-31010

Unavailable

20

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13
