Suzuki GT550 (1972) FRONT WHEEL Diagram

#

Description
Price

1

HUB | FROM 54110-31001; Includes Item(s) 2

54100-31830

Unavailable

2

BEARING, LH This part replaces 08143-62020.

08143-62027

$16.01

3

PANEL, RH

54210-31002

Unavailable

4

PANEL, LH

54250-31002

Unavailable

5

SHOE SET, FR BR This part replaces 54410-31001.

54401-07840

Unavailable

6

SPRING

55420-30000

$4.48

7

CAM, BRAKE This part replaces 54440-33000.

54440-33002

Unavailable

8

CAM, BRAKE RH

54430-31001

Unavailable

9

WASHER | 15x24x1.6 This part replaces 09160-15001.

09160-15048

$2.56

10

O RING (ID:14.8,D:2.40) This part replaces 09280-15001.

09280-15003

$1.76

11

GEAR, SPEEDOMETER

54611-31000

Unavailable

12

PINION, SPEEDOMETER

54621-31000

Unavailable

13

BUSH This part replaces 54632-11020.

54632-49200

Unavailable

14

WASHER,5.1X9X0. | 5.1x9x0.4 This part replaces 09160-05001.

09160-05001-A05

$1.87

15

DRIVER This part replaces 54660-11030.

54660-11031

$12.67

16

THRUST WASHER | 5.1x9x0.4

09160-22001

$2.47

17

CIRCLIP This part replaces 08331-11229.

08331-31229

$2.48

18

AXLE, FRONT

54711-33000

Unavailable

19

NUT, FRONT AXLE

54721-31000

Unavailable

20

LEVER, FRONT BRAKE CAM (1)

54451-31001

Unavailable

21

LEVER, FRONT BRAKE CAM (2)

54561-31001

Unavailable

22

SPRING This part replaces 09448-30001.

09448-30001-XC0

Unavailable

23

SPRING

09448-30002

Unavailable

24

PIN

09200-06001

Unavailable

25

WASHER This part replaces 08322-21068.

08322-01067

$2.13

26

PIN This part replaces 04111-12108.

04111-1210A

$1.50

27

BOLT This part replaces 01112-06258.

01500-06257

$1.97

28

ROD, CAM LEVER CONNECTING

54470-31000

Unavailable

29

END, CONNECTING ROD FRONT

54481-31000

Unavailable

30

END, CONNECTING ROD REAR

54482-31000

Unavailable

31

.NUT This part replaces 08311-11068.

08310-00067

$2.13

32

SEAL,OIL(26X38X | 25.4x38x6 This part replaces 09285-26001.

09285-26005

Unavailable

33

OIL SEAL | 6x10x4

09289-06001

$4.58

34

COVER, BRAKE AIR INTAKE INNER

54674-31000

Unavailable

35

COVER, BRAKE AIR INTAKE OUTER

54675-31000

Unavailable

36

SCREW This part replaces 02111-04087.

02112-04087

$1.49

37

CAP, BRAKE AIR OUTLET

54676-31000

Unavailable

38

LINK, FRONT TORQUE

54311-34000

Unavailable

39

BOLT

09119-10008

Unavailable

40

WASHER

09167-10004

Unavailable

41

NUT This part replaces 08312-12108.

08310-00107

$2.19

42

TIRE | FROM 55100-31011 AND 55100-31012

55100-31600

Unavailable

43

TUBE | 3.25-19

55100-15010

Unavailable

44

PROTECTOR, WHEEL INNER TUBE FRONT | 22-19 This part replaces 55261-15010.

55261-15020

$3.15

45

RIM, WHEEL | 1.85B-19

55311-15020

Unavailable

46

SPOKER SET

55301-31805

Unavailable

47

BALANCER WHEEL (30G) | 30G This part replaces 55412-11000.

55413-41F00

$7.50

48

BALANCER WHEEL (15G) | 20G This part replaces 55411-11000.

55411-26G00

$7.73
