Suzuki GSX-S750AM2 (2022) THROTTLE BODY (E33) Diagram

#

Description
Price

1

BODY ASSY,THROTTLE

13405-13K11

$1,477.88

2

SPRING,THROTTLE SCREW

13268-48700

$3.97

3

SCREW

13269-33E00

$10.45

4

O-RING

13295-29901

$3.97

5

.O-RING

13575-29G01

$2.97

6

.SENSOR

13580-14J00

$169.70

7

.SENSOR ASSY

13580-29G00

$109.53

8

.SCREW

13605-02F00

$3.50

9

SCREW This part replaces 13602-05A40.

02112-0412A

$1.24

10

WASHER

13606-47A00

$3.70

11

.O-RING

13679-37H00

$8.21

12

.HOSE

13698-08J01

$32.95

13

.HOSE

13698-08J11

$32.95

14

.MOTOR ASSY

18117-14J01

$436.22
