Sea-doo GSX RFI, 5637/5638/5652/5829, 1999 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$76.67

2

OIL CAP - Call your local BRP dealership | Includes 17 to 18

275000221

Unavailable

3

GASKET - Call your local BRP dealership This part replaces 293250075.

293250211

Unavailable

4

Filler Neck

275000187

Unavailable

5

Gasket

293250029

$12.06

6

Filler Neck Nut, Fuel

211100012

$10.02

7

OIL LEVER SENSOR ASS'Y - Call your local BRP dealership

278001401

Unavailable

7

Grommet

293720008

$10.91

8

Wire Seal

278000218

$3.48

9

Male Terminal | XT Models

278000222

$2.55

10

Female Housing, 2 Circuits

278000217

$7.59

11

Filler Hose

275000188

Unavailable

12

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

13

Was 275500008 Hose 12 mm

219704356

$5.94

14

Was 293550004 Dielectric Grease, 150 g

219704453

$36.54

15

Tie Wrap 94 mm | 4X4

293750001

$0.83

16

Tridon Clamp

293650035

$5.80

17

Tridon Gear Clamp

293650170

$1.74

18

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

19

Check Valve

275500398

$8.57

20

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$27.27

21

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

22

Oetiker Clamp

293650042

$1.40

23

Grommet

293720008

$10.91

24

Restrictor

275000190

Unavailable

25

Snap Cap, Black

293000076

Unavailable

26

Tie Wrap 142 mm

293750002

$0.88

27

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

$10.74

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

Unavailable

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

SYNTHETIC INJECTION OIL, 12 X 1 LITER - Call your local BRP dealership

413710500

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable
