2013 Suzuki GSX-R250L3 Muffler Diagram

← All diagrams

Find the part on the Muffler diagram for your 2013 Suzuki GSX-R250L3, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Suzuki GSX-R250L3 Muffler Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

EXHAUST

14100-48H00-000

—
Out of stock

2

GASKET, EXHAUST PIPE

14181-46E20-000

—
Out of stock

3

MUFFLER RH

14305-48H01-000

—
Out of stock

4

MUFFLER LH

14306-48H02-000

—
Out of stock

5

CLAMP, MUFFLER CONNECTOR RH

14459-48H00-000

—
Out of stock

6

CLAMP, MUFFLER CONNECTOR LH

14469-48H00-000

—
Out of stock

7

COVER, MUFFLER FRONT RH

14750-48H00-000

—
Out of stock

8

COVER, MUFFLER FRONT LH

14760-48H00-000

—
Out of stock

9

CONNECTOR, JOINT

14771-38F10-000

—
Out of stock

10

GROMMET

14795-10FA0-000

—
Out of stock

11

SCREW (6X16)

09139-06030-000

—
Out of stock

12

WASHER (6.5X18.0X1.0)

09160-06164-000

—
Out of stock

13

WASHER (8.5X30X1.6)

09160-08149-000

—
Out of stock

14

SPACER (6.5X9X5)

09180-06365-000

—
Out of stock

15

SPACER

09180-08L02-000

—
Out of stock

16

CUSHION

09320-08082-000

—
Out of stock

17

CUSHION

09320-12L04-000

—
Out of stock

18

BOLT (8X16)

01550-0816A-000

—
Out of stock

19

BOLT

01550-0840A-000

—
Out of stock

20

BOLT

01550-0840A-000

—
Out of stock

21

BOLT

07130-0830A-000

—
Out of stock

22

NUT

08316-1008A-000

—
Out of stock

23

STAY, MUFFLER REAR COVER

14770-48H01-000

—
Out of stock

24

WASHER (6.5X18X1)

09160-06028-000

—
Out of stock

25

.SPACER (6.2X8.4X10.9)

09180-06331-000

—
Out of stock

26

CUSHION

09320-08068-000

—
Out of stock

27

BOLT

07130-0620A-000

—
Out of stock

28

COVER, MUFFLER REAR (GRAY)

14790-48H01-YYK

2
Out of stock

29

BOLT (6X16)

07130-0616A-000

—
Out of stock

30

COVER, MUFFLER BODY RH

14781-48H00-000

—
Out of stock

31

COVER, MUFFLER BODY LH

14730-48H00-000

—
Out of stock

32

SCREW (6X16)

09139-06030-000

—
Out of stock

33

WASHER (6.5X18.0X1.0)

09160-06164-000

—
Out of stock

34

SPACER (6.5X9X5)

09180-06365-000

—
Out of stock

35

CUSHION

09320-08082-000

—
Out of stock

36

SENSOR, OXYGEN

18213-23H01-000

—
Out of stock

37

CLAMP, OXYGEN SENSOR LEAD

36990-32G20-000

—
Out of stock
