2013 Suzuki GSX-R250L3 Handlebar Diagram

← All diagrams

Find the part on the Handlebar diagram for your 2013 Suzuki GSX-R250L3, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Suzuki GSX-R250L3 Handlebar Diagram

#

Description
Price
Status
Order Qty

1

HANDLEBAR RH

56111-48H00-000

Out of stock

2

HANDLEBAR LH

56151-48H00-000

Out of stock

3

HOLDER, HANDLEBAR RH

56211-48H00-000

Out of stock

4

HOLDER, HANDLEBAR LH

56221-48H00-000

Out of stock

5

EXPANDER, HANDLE BALANCER

56272-10G00-000

Out of stock

6

EXPANDER, HANDLE BALANCER

56272-42F00-000

Out of stock

7

.NUT,HANDLE BALANCER

56273-10G10-000

Out of stock

8

BALANCER, HANDLEBAR

56278-48H00-000

Out of stock

9

.WASHER (6.5X16X4)

09160-06131-000

Out of stock

10

SPACER (6.5X16X15)

09180-06161-000

Out of stock

11

PLUG (OD:22)

09250-18003-000

Out of stock

12

BOLT

07130-0680B-000

Out of stock

13

BOLT

07130-0825A-000

Out of stock

14

BOLT

07130-0830A-000

Out of stock

15

MIRROR ASSY, REAR VIEW RH

56500-48H10-000

Out of stock

16

MIRROR ASSY, REAR VIEW LH

56600-48H10-000

Out of stock

17

CABLE ASSY, CLUTCH

58200-48H00-000

Out of stock

18

CABLE ASSY, THROTTLE NO.1

58300-48H00-000

Out of stock

19

CABLE ASSY, THROTTLE NO.2

58300-48H10-000

Out of stock

20

GUIDE, GUIDE

58620-48H31-000

Out of stock

21

GUIDE, CLUTCH CABLE

58621-48H00-000

Out of stock

22

GUIDE, CABLE

58621-48H10-000

Out of stock

23

PIN

09200-06071-000

Out of stock

24

.BOLT

01550-0612B-000

Out of stock

25

SCREW

02142-0510B-000

Out of stock

26

PIN

04111-2015A-000

Out of stock
