2013 Suzuki GSX-R250L3 Front Wheel Diagram

← All diagrams

Find the part on the Front Wheel diagram for your 2013 Suzuki GSX-R250L3, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Suzuki GSX-R250L3 Front Wheel Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

WHEEL, FRONT(17M/CXMT3.00) (BLACK)

54111-48H00-YGA

1
Out of stock

2

SPACER, FRONT HUB BEARING

54731-48H00-000

—
Out of stock

3

SEAL, FRONT WHEEL BEARING

54742-12FH0-000

—
Out of stock

4

BEARING

08123-63027-000

—
Out of stock

5

VALVE ASSY,WHEEL RIM (TR412)

43130-24A00-000

—
Out of stock

6

TIRE, FRONT (110/80-17M/C 57H)

55110-48H00-000

—
Out of stock

7

AXLE, FRONT

54711-48H00-000

—
Out of stock

8

SPACER, FRONT AXLE LH

54751-48H00-000

—
Out of stock

9

DISC, FRONT BRAKE

59221-48H00-000

—
Out of stock

10

BOLT, FRONT BRAKE DISC

59421-48H00-000

—
Out of stock

11

BALANCER,WHEEL NO.1 (10G) | 10G

55411-22H00-000

—
Out of stock

11

BALANCER,WHEEL NO.2 (20G) | 20G

55412-22H00-000

—
Out of stock

11

BALANCER,WHEEL NO.3 (30G) | 30G

55413-22H00-000

—
Out of stock
