Find the part on the Battery diagram for your 2013 Suzuki GSX-R250L3, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Suzuki GSX-R250L3 Battery Diagram

#

Description
Price
Status
Order Qty

1

BATTERY ASSY (YTX9-BS, 12V8AH)

33610-32C10-000

Out of stock

2

BAND, BATTERY

33651-48H00-000

Out of stock

3

PROTECTOR, BATTERY

33652-48H00-000

Out of stock

4

PROTECTOR, BATTERY

33652-48H10-000

Out of stock

5

WIRE, STARTER MOTOR LEAD

33810-48H00-000

Out of stock

6

CAP, STARTER MOTOR RELAY

31861-48H00-000

Out of stock

7

WIRE, BATTERY PLUS LEAD

33820-48H00-000

Out of stock

8

CAP, STARTER MOTOR RELAY

31861-48H10-000

Out of stock

9

WIRE, BATTERY MINUS LEAD

33860-48H00-000

Out of stock
