2013 Suzuki GSX-R250L3 Handle Switch Diagram

← All diagrams

Find the part on the Handle Switch diagram for your 2013 Suzuki GSX-R250L3, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Suzuki GSX-R250L3 Handle Switch Diagram

#

Description
Price
Status
Order Qty

1

SWITCH ASSY, HANDLE RH

37200-48H20-000

Out of stock

2

.SCREW

02112-0530B-000

Out of stock

3

CLAMP (L:248)

09407-25402-000

Out of stock

4

SWITCH ASSY, HANDLE LH

37400-48H20-000

Out of stock

5

.SCREW

02112-0525B-000

Out of stock

6

.SCREW

02112-0545B-000

Out of stock

7

CLAMP (L:248)

09407-25402-000

Out of stock
