Suzuki GSX-R1000 (2004) FRONT CALIPER (MODEL K4) Diagram

#

Description
Price

1

CALIPER ASSY, FRONT RH

59100-29G10-999

Unavailable

1

CALIPER ASSY, FRONT LH | Includes Item(s) 2 - 8

59300-29G10-999

Unavailable

2

PISTON SET

59100-35850

$78.20

3

SEAL SET, PISTON

59300-29850

$75.15

4

PIN, PAD

59141-18G00

$35.53

5

BOLT

59145-18G00

$11.20

6

SPRING, PAD

59151-29G00

$12.28

7

BLEEDER

59121-18410

$8.35

8

CAP

55156-66310

$4.94

9

PAD SET

59100-29820

$69.42

10

BOLT

09106-10076

$4.55
