Sea-doo GSX, 5624, 1997 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$88.03

2

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

3

Grommet

293720008

$12.52

4

Oil Cap | Includes 4 - 5.

275000197

Unavailable

5

Snap Cap

293000065

Unavailable

6

Tie-Rap 180 mm

414115200

$0.10

7

Filler Neck

275000187

Unavailable

8

Restrictor

275000190

Unavailable

9

Instant Gasket

219701421

$51.99

10

Gasket

293250029

$13.85

11

Filler Neck Nut, Fuel

211100012

$11.51

12

Filler Hose

275000188

Unavailable

13

Tridon Clamp

293650035

$6.66

14

Was 275500008 Hose 12 mm

219704356

$6.82

15

Tridon Gear Clamp

293650170

$2.00

16

Was 415110000 Polyurethane Hose 5.2 mm

219704414

$114.15

17

Tie Wrap 94 mm | 4X4

293750001

$0.96

18

Check Valve This part replaces 275500087.

275501246

Unavailable

19

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$31.31

20

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

21

Oetiker Clamp

293650042

$1.61

22

Oil Level Sensor

278000478

Unavailable

23

Wire Seal

278000218

$4.00

24

Male Terminal | XT Models

278000222

$2.93

25

Female Housing, 2 Circuits

278000217

$8.72

26

GASKET - Call your local BRP dealership This part replaces 293250075.

293250211

Unavailable

37

Grommet

204470104

Unavailable
