1982 Suzuki GS650G Right Handle Switch Diagram

← All diagrams

Find the part on the Right Handle Switch diagram for your 1982 Suzuki GS650G, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Suzuki GS650G Right Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

1
Out of stock

2

SWITCH ASSY, HANDLE RH This part replaces 37200-49470.

37200-49471

1
Out of stock

2

NO DESCRIPTION AVAILABLE | Includes Item(s) 3 This part replaces 37200-49450.

37200-49451

1
Out of stock

3

2

$1.86

In stock

4

LEVER, BRAKE

57420-49101

1

$33.82

In stock

5

BOLT

57431-18621

1
Out of stock

6

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

8

HOLDER

57465-18601

1

$4.33

In stock

9

COVER

57481-33010

1

$5.98

In stock

10

2

$2.43

In stock

11

2

$1.27

In stock

12

2

$2.10

In stock

13

BAND (L:120)

09407-12402

1
Out of stock
