1978 Suzuki GS400X RH Handle Switch Diagram

← All diagrams

Find the part on the RH Handle Switch diagram for your 1978 Suzuki GS400X, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1978 Suzuki GS400X RH Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CASE ASSY,THROT | Includes Item(s) 2 - 6 This part replaces 57100-45000.

57100-45040

1
Out of stock

2

GRIP, THROTTLE

57110-45000

1

$46.98

In stock

3

BUTTON, STERTING

57371-45000

1

$5.10

In stock

4

CONTACT

57372-45000

1

$5.02

In stock

5

SPRING

57382-45000

1

$3.80

In stock

6

2

$1.61

In stock

7

LEVER, BRAKE | Includes Item(s) 8 - 12 This part replaces 57300-39100.

57420-11300

—
Out of stock

8

LEVER, BRAKE This part replaces 57420-39100.

57420-11300

—
Out of stock

9

BOLT This part replaces 57431-18620.

57431-18621

1
Out of stock

10

1

$2.28

In stock

11

NUT

57433-11010

1
Out of stock

12

1

$0.96

In stock

13

1

$44.47

In stock
