Suzuki GS400X (1978) REAR COMBINATION LAMP Diagram

#

Description
Price

1

LAMP ASSY, REAR COMBINATION | C,XC; Includes Item(s) 2 - 6

35710-45011

Unavailable

2

LENS,RR COMBI L | C,XC This part replaces 35712-45011.

35712-45013

Unavailable

3

GASKET | C,XC

35713-45010

Unavailable

4

BULB | C,XC; 12V, 23/8W

09471-12035

$4.11

5

SCREW 4X55 | C,XC This part replaces 02111-04558.

02112-04558

$1.67

6

GASKET | C,XC

35627-43010

$2.29

7

WASHER | C,XC This part replaces 08322-21068.

08322-01067

$1.86

8

LOCK WASHER | C,XC This part replaces 08321-21068.

08321-01067

$1.83

9

BOLT | C,XC This part replaces 01107-06128.

01500-06127

$1.97

10

NO DESCRIPTION AVAILABLE | C,XC This part replaces 35927-45002.

35927-45003

Unavailable

11

BRACKET, LICENSE PLATE | C,XC This part replaces 35928-45000.

35928-45001

Unavailable
