1977 Yamaha GS340A Tachometer Unit Diagram

← All diagrams

Find the part on the Tachometer Unit diagram for your 1977 Yamaha GS340A, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1977 Yamaha GS340A Tachometer Unit Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

TACHOMETER ASSEMBLY

(861-83540-01-00)

1
Out of stock

2

BULB (12V-3.4W)

123-83516-21-00

1

$4.10

In stock

3

SOCKET, METER

(861-83536-40-00)

1
Out of stock

4

NUT, HEXAGON (663)

95380-05600-00

1

$6.17

In stock

5

YBS67-5 WASHER, SPRING

92990-05100-00

1
Out of stock

6

. DAMPER

861-83523-40-00

1
Out of stock

7

. PLATE, FITTING

861-83514-40-00

1
Out of stock

8

TACHOMETER CABLE (843-83560-00)

843-83560-01-00

1
Out of stock

9

CAP, HOUSING

821-17819-00-00

1
Out of stock

10

OIL SEAL (6X12X4-821)

93104-06033-00

1

$6.49

In stock

11

BUSH, DRIVEN GEAR OUTER

821-17843-00-00

1
Out of stock

12

GEAR, DRIVEN (10T)

813-17841-00-00

1
Out of stock

13

COVER, OIL PUMP

(8E3-15416-00-00)

1
Out of stock

14

OIL SEAL (J10)

93101-10090-00

1

$6.17

In stock

15

SHAFT, WORM

826-13175-00-00

1
Out of stock

16

GASKET 2

859-15466-09-00

1
Out of stock

17

SCREW, PAN HEAD(62X)

97885-05010-00

1

$2.65

In stock

18

GSKT,O PMPCVR

838-15456-09-00

1
Out of stock

19

GASKET

821-17818-02-00

—

$5.66

In stock
