1972 Yamaha DS7 (DS7) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1972 Yamaha DS7 (DS7), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1972 Yamaha DS7 (DS7) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CRANK,KICK

278-15611-00-00

1
Out of stock

2

COVER, KICK LEVER

156-15618-01-00

1

$6.43

In stock

3

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

4

BALL (12R)

93507-32031-00

1
Out of stock

5

BOSS, KICK CRANK

583-15621-00-00

1
Out of stock

6

BOLT, HEXAGON

97013-08030-00

1

$3.20

In stock

7

WASHER PLATE 278156130000

90201-15234-00

1

$6.78

In stock

8

CIRCLIP

99006-10600-00

1

$6.91

In stock

9

OIL SEAL (20X30X4.5-146)

93104-20007-00

1

$6.23

In stock

10

SPRING TORSION 278156650000

90508-30051-00

1
Out of stock

11

STOPPER, KICK SPRING

248-15668-00-00

1
Out of stock

12

WASHER PLATE 132172160000

90201-20266-00

1
Out of stock

13

CIRCLIP(1AR)

99009-20400-00

1
Out of stock

14

SPACER (278-15666-01)

278-15666-00-00

1
Out of stock

15

COVER,SPRING

278-15676-00-00

1
Out of stock

16

WHEEL, RATCHET

278-15671-01-00

1
Out of stock

17

CLIP

90468-26045-00

1
Out of stock

18

CIRCLIP (4L0)

93440-25084-00

—

$3.96

In stock

19

WASHER PLATE 152172260000

90201-25490-00

—
Out of stock

20

WASHER, WAVE

(90206-25029-00)

1
Out of stock

21

GEAR, KICK

278-15641-01-00

1
Out of stock

22

KICK AXLE ASSEMBLY

278-15660-01-00

1
Out of stock

23

SHIM 1

136-17417-00-10

1
Out of stock
