Find the part on the Right Handle Switch diagram for your 1995 Suzuki DR250SES, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1995 Suzuki DR250SES Right Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, THROTTLE

57110-14D00

1

$31.75

In stock

3

PIECE, GUIDE

57122-13600

1
Out of stock

4

COVER

57129-13601

1

$13.50

In stock

5

1

$1.31

In stock

6

SCREW

02112-05164

2

$2.87

In stock

7

LEVER, BRAKE

57421-03D00

1

$14.77

In stock

8

SCREW

57431-05D00

1

$14.50

In stock

9

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

10

BOLT, ADJUST

57431-14511

1
Out of stock

11

NUT This part replaces 08310-12055.

08310-0005A

1
Out of stock

12

SPRING, RETURN

57318-14502

1
Out of stock

13

SWITCH ASSY,FR BRAKE | Includes Item(s) 14 This part replaces 57460-17C00.

57460-14J02

1
Out of stock

14

SCREW

57465-17C00

1
Out of stock

15

COVER, KNUCKLE RH (BLUE)

57341-05D00-0NF

1

$45.43

In stock

16

SCREW

09125-05042

1
Out of stock

17

1

$2.45

In stock

18

.WASHER (6.5X16X1.6) This part replaces 09160-06042.

09160-06130

1
Out of stock

19

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

20

SWITCH ASSY,HAN | Includes Item(s) 21 This part replaces 37200-14D01.

37200-44E00

1
Out of stock

21

.SCREW This part replaces 02112-05166.

02112-0516A

1
Out of stock

22

BAND

09407-12402

2
Out of stock

23

REFER TO FIG.40A(G-11) FOR

SPECIAL NOTE

—
Out of stock
