2004 Suzuki DR-Z400S Tail Lamp Diagram

← All diagrams

Find the part on the Tail Lamp diagram for your 2004 Suzuki DR-Z400S, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2004 Suzuki DR-Z400S Tail Lamp Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

1

$114.89

In stock

2

1

$68.03

In stock

2A

.GASKET LENS

35713-14D30

1

$8.91

In stock

3

SCREW (4X45)

09125-04501

2

$3.13

In stock

4

BULB (12V,21/5W) This part replaces 09471-12083.

09471-12128

1
Out of stock

5

CUSHION

09320-10501

2
Out of stock

6

SPACER (6.5X10X10)

09180-06310

2
Out of stock

7

.WASHER (6.5X20X1.6)

09160-06088

2

$1.80

In stock

8

NUT This part replaces 08316-10063.

08316-1006B

2
Out of stock

9

1

$18.13

In stock

10

.WASHER (6.5X20X1.6)

09160-06088

2

$1.80

In stock

11

SCREW This part replaces 02142-06123.

02142-0612A

2
Out of stock

12

NUT This part replaces 08316-10063.

08316-1006B

2
Out of stock

13

CUSHION

09321-06026

2
Out of stock

14

REFLECTOR ASSY, RR SIDE This part replaces 35970-07F00.

35970-07F01

1
Out of stock

15

NUT This part replaces 08316-10053.

08316-1005A

1
Out of stock
