Description

Price

1

HANDLEBAR (SILVER)

56111-28K00-YUS

$119.87

2

BALANCER SET, HANDLEBAR

56200-32861

$55.07

3

.SCREW

02122-0680B

$4.03

4

.SPACER, KNUCKLE COVER

57346-14G00

$19.62

5

.WASHER (6.5X16X4)

09160-06131

$2.53

6

.EXPANDER,HANDLE BALANCER

56272-10G01

$4.44

7

.NUT,HANDLE BALANCER

56273-10G10

$7.92

8

MIRROR ASSY, RR VIEW RH

56500-04F30

$134.12

9

MIRROR ASSY, RR VIEW LH

56600-04F30

$134.10

10

CABLE ASSY, CLUTCH

58200-11J00

$47.41

11

GUIDE, CLUTCH CABLE

58631-11J10

Unavailable

12

STOPPER,CLUTCH CABLE

58634-44H00

$17.40

13

BOLT

01547-0612A

$2.01

14

CABLE ASSY, THROTTLE NO.1

58300-11J01

$44.82

15

CABLE ASSY, THROTTLE NO.2

58300-11J11

$42.95

16

SCREW (5X10)

09125-05042

$1.98

Suzuki DL650AM2 (2022) HANDLEBAR (DL650XAM2 E33) Diagram
