Honda CL175A MOTORCYCLE, JPN, VIN# CL175-1000001 DRAIN VALVE Diagram

#

Description
Price

1

COVER, CRANKCASE (LOWER) (NOT AVAILABLE)

11311-235-000

Unavailable

2

GSKT, COVER (LOWER) This part replaces 11396-235-000.

11396-235-306

Unavailable

3

BOLT, DRAIN VALVE

90013-230-000

Unavailable

4

GASKET, DRAIN This part replaces 90407-205-000.

90407-367-690

$4.15

4

GASKET, DRAIN

90407-367-690

$4.15

5

WASHER, DRAIN PLUG (12MM) This part replaces 90407-231-000.

94109-12000

$1.49

5

GASKET, DRAIN VALVE (12.5X20)

90407-259-000

$2.92

5

WASHER, DRAIN PLUG (12MM)

94109-12000

$1.49

6

WASHER, SEAL (8MM)

90441-286-000

$1.90

7

BOLT, HEX. (6X20) This part replaces 92000-06020.

92101-06020-0A

$1.49

7

BOLT, HEX. (6X20)

92101-06020-0A

$1.49

8

BOLT, HEX. (6X35) This part replaces 92000-06036.

92201-06035-0A

$1.75

8

BOLT, HEX. (6X35) This part replaces 92200-06035.

92201-06035-0A

$1.75

8

BOLT, HEX. (6X35)

92201-06035-0A

$1.75

9

BOLT, HEX. (6X56) (NOT AVAILABLE) This part replaces 92000-06056.

92000-06056-0A

Unavailable

9

BOLT, HEX. (6X56) (NOT AVAILABLE)

92000-06056-0A

Unavailable

10

BOLT, HEX. (6X95) (SOURCE: VINTAGE PARTS INC.)

92000-06095

Unavailable

11

BOLT, HEX. (8X106) (SOURCE: VINTAGE PARTS INC.) | Use up to Engine SN 1017783 This part replaces 92000-08106.

92101-08105-0A

Unavailable

11

BOLT, HEX. (8X106) (SOURCE: VINTAGE PARTS INC.) This part replaces 92000-08106-0A.

92101-08105-0A

Unavailable

11

BOLT, HEX. (8X106) (SOURCE: VINTAGE PARTS INC.)

92101-08105-0A

Unavailable

11

BOLT, HEX. (8X106) (SOURCE: VINTAGE PARTS INC.) This part replaces 92101-08106-0A.

92101-08105-0A

Unavailable

12

BOLT, HEX. (8X130) | Use up to Engine SN 1017783 This part replaces 92000-08132.

92101-08130-0A

Unavailable

12

BOLT, HEX. (8X130) This part replaces 92000-08132-0A.

92101-08130-0A

Unavailable

13

BOLT, DRAIN PLUG (12MM)

92800-12000

$3.23

14

NUT, CAP (8MM) | Use up to Engine SN 1017783 This part replaces 90012-286-000.

94021-08000-0S

$1.55

14

NUT, CAP (8MM) | Use up to Engine SN 1017783 This part replaces 94021-08000.

94021-08000-0S

$1.55

14

NUT, CAP (8MM)

94021-08000-0S

$1.55

14

NUT, CAP (8MM) | Use up to Engine SN 1017783 This part replaces 94022-08000-0S.

94021-08000-0S

$1.55

15

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

15

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

15

WASHER, PLAIN (6MM)

94101-06800

$1.49

16

WASHER, PLAIN (8MM)

94101-08000

$1.49
