2015 Kawasaki ZR800 (European) Throttle Diagram

← All diagrams

Find the part on the Throttle diagram for your 2015 Kawasaki ZR800 (European), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2015 Kawasaki ZR800 (European) Throttle Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11065

CAP

11065-0072

1
Out of stock

13272

1

$3.80

In stock

14092

COVER,THROTTLE,LH

14092-0952

1
Out of stock

14092A

COVER,THROTTLE,RH

14092-0953

1
Out of stock

16014

SCREW-PILOT AIR

16014-0017

1
Out of stock

16021

SCREW-THROTTLE STOP

16021-0029

1
Out of stock

16073

INSULATOR,INJECTER

16073-1123

1
Out of stock

31064

PIPE-COMP,FUEL

31064-0625

1
Out of stock

49033

NOZZLE-INJECTION

49033-0029

1
Out of stock

49056

PIPE-INJECTION

49056-0037

1
Out of stock

92005

FITTING

92005-1380

1
Out of stock

92037

CLAMP,TUBE

92037-1124

1
Out of stock

92039

RIVET

92039-0023

1
Out of stock

92055

RING-O,INJECTION NOZZLE

92055-0124

1
Out of stock

92055A

RING-O

92055-0761

1
Out of stock

92152

COLLAR

92152-1709

1
Out of stock

92154

BOLT,SOCKET,5X12

92154-0917

1
Out of stock

92154A

BOLT,FLANGED,5X8

92154-0964

1
Out of stock

92170

CLAMP

92170-3749

1
Out of stock

92172

SCREW,PIPE INJECTION

92172-0828

1
Out of stock

92191

TUBE,3.2X7.4X40

92191-1551

1
Out of stock

92191A

TUBE,3.2X7.4X70

92191-1552

1
Out of stock

92192

TUBE,3.2X7.4X90

92192-1265

1
Out of stock

92192A

TUBE,3.2X7.4X100

92192-1266

1
Out of stock

92200

WASHER

92200-3807

1
Out of stock

16163

THROTTLE-ASSY

16163-0798

1
Out of stock

16163A

THROTTLE-ASSY

16163-0800

1
Out of stock

99999

KIT.,72KW

99999-0345

1
Out of stock
