Honda Z50AA MOTORCYCLE, JPN, VIN# Z50A-100001 TO Z50A-120087 FUEL TANK Diagram

#

Description
Price

1

PETCOCK ASSY. | Use up to Frame SN 242186 This part replaces 16950-044-004.

16950-045-005

$38.67

1

PETCOCK ASSY. | Use up to Frame SN 242186

16950-045-005

$38.67

9

GASKET, TURN BUCKLE NUT (NOT AVAILABLE) | Use up to Frame SN 242186

16958-044-004

Unavailable

11

SPRING, VALVE (NOT AVAILABLE) | Use up to Frame SN 242186

16960-044-004

Unavailable

12

NUT, TURN BUCKLE (NOT AVAILABLE) | Use up to Frame SN 242186

16962-044-004

Unavailable

14

SCREW, LEVER STOPPER (NOT AVAILABLE) | Use up to Frame SN 242186

16963-044-004

Unavailable

15

O-RING (7X1.7) | Use up to Frame SN 242186 This part replaces 16997-044-004.

91312-107-000

$3.18

15

O-RING (7X1.7) | Use up to Frame SN 242186

91312-107-000

$3.18

16

TANK, FUEL *R3C/NH35* (CANDY RED AND CLOUD SILVER) (NOT AVAILABLE) This part replaces 17500-045-670BV.

17500-045-670BR

Unavailable

16

TANK, FUEL *Y3L/Y16L* (IVORY WHITE & BRIGHT YELLOW) (NOT AVAILABLE)

17500-045-670BW

Unavailable

16

TANK, FUEL *YR19L* (CAMEL YELLOW) (NOT AVAILABLE)

17500-045-670CJ

Unavailable

16

TANK, FUEL *R3C/NH35* (CANDY RED AND CLOUD SILVER) (NOT AVAILABLE)

17500-045-670BR

Unavailable

17

RUBBER, FR. FUEL TANK | Use up to Frame SN 173239

17611-045-020

Unavailable

18

RUBBER, RR. FUEL TANK

17613-045-000

$14.21

19

CAP, FUEL FILLER This part replaces 17620-045-010.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-045-670.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-045-671.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-165-642.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-943-003.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-958-003.

17620-165-643

$42.47

19

CAP, FUEL FILLER This part replaces 17620-958-013.

17620-165-643

$42.47

20

GASKET, CAP (NOT AVAILABLE)

17631-045-000

Unavailable

21

BAND, FUEL TANK MOUNT (NOT AVAILABLE)

17670-045-670

Unavailable

23

EMBLEM, R. FUEL TANK (NOT AVAILABLE)

87121-045-670

Unavailable

24

EMBLEM, L. FUEL TANK (NOT AVAILABLE)

87122-045-670

Unavailable

26

PLATE A, CAUTION (NOT AVAILABLE)

87504-045-670

Unavailable

30

SCREW, OVAL (3X8)

93700-03008-0B

$1.31

31

BULK HOSE, FUEL (4.5X3000) (4.5)

95001-45003-60M

$36.67

31

TUBE (4.5) This part replaces 95001-45000-90.

95001-45000-40

Unavailable

31

TUBE (4.5) This part replaces 95001-45100.

95001-45000-40

Unavailable

31

TUBE (4.5) This part replaces 95001-45100-90.

95001-45000-40

Unavailable

32

CLIP, TUBE (C8)

95002-45000

$1.49
