Kawasaki Z125 PRO KRT EDITION Crankcase Diagram

Description

Price

11009

GASKET,8.2X14X1.0

11009-1344

$3.17

11061

GASKET,DRAIN PLUG

11061-0421

$5.89

13070

GUIDE

13070-0069

$2.24

14080

CRANKCASE,LH

14080-0747

$104.20

14080A

CRANKCASE,RH

14080-0752

$112.38

220

SCREW-PAN-CROSS,6X14

220AA0614

$1.48

220A

SCREW-PAN-CROS,6X12

220AC0612

$1.71

220B

SCREW-PAN-CROS,6X50

220AC0650

$2.00

220C

SCREW-PAN-CROS,6X75

220AC0675

$2.26

235

SCREW-PAN-WP-CROS,5X10

235AA0510

$3.67

235A

SCREW-PAN-WP-CROS,6X14

235AA0614

$4.18

32151

PIPE

32151-1961

$6.41

39193

PIPE-OIL

39193-1056

$53.52

601

BEARING-BALL

601A6201

$10.69

601A

BEARING-BALL,#6203

601A6203

$14.12

670

O RING,9.8X1.9

670B1510

$4.31

92001

BOLT,RETURN SPRING

92001-1455

$4.69

92004

STUD,8X190

92004-1281

$4.11

92043

PIN,6.2X8X14

92043-1263

$0.43

92045

BEARING-BALL,6804

92045-0758

$27.43

92046

BEARING-NEEDLE,HK1312

92046-1148

$18.74

92049

SEAL-OIL,SC22325

92049-1048

$8.86

92049A

SEAL-OIL

92049-1559

$3.54

92066

PLUG,OIL DRAIN,12X15

92066-0753

$5.01

92153

BOLT,8X20

92153-0570

$1.08
