Kawasaki Z1000 Cowling(Upper) Diagram
#
Description
Price
11055
BRACKET,METER
11055-1700
$30.24
11056
BRACKET,HEAD LAMP
11056-0707
$73.29
13061
BOSS
13061-0378
$11.54
14092
COVER,FORK,LH,F.BLACK
14092-0017-6Z
$36.44
14092A
COVER,FORK,RH,F.BLACK
14092-0018-6Z
$36.44
14092B
COVER,COWLING
14092-0082
$154.34
39156
PAD
39156-0284
$1.33
39156A
PAD,RUBBER
39156-0548
$2.73
39156B
PAD
39156-0632
$4.22
55028F
COWLING,UPP,CNT,F.S.BLACK
55028-0362-18T
$168.85
55028J
COWLING,UPP,LH,G.B.GREEN
55028-0363-40R
$88.86
55028N
COWLING,UPP,RH,G.B.GREEN
55028-0364-40R
$88.86
92015
NUT,WELL,5MM
92015-1757
$7.29
92022
WASHER,NYLON,5.3X11.5X1.5
92022-1521
$3.92
92039
RIVET
92039-0051
$4.65
92075
DAMPER
92075-1028
$4.69
92075A
DAMPER
92075-1964
$5.00
92077
KNOB
92077-0027
$16.23
92145
SPRING
92145-0756
$4.14
92154
BOLT,SOCKET,5X16
92154-0026
$2.55
92154A
BOLT,SOCKET,5X16
92154-0209
$2.75
92154C
BOLT,6X42
92154-0540
$10.47
92161
DAMPER,TAIL LAMP
92161-0191
$4.60
92161A
DAMPER,6.3X22X30
92161-0865
$2.91
92172
SCREW,TAPPING,5X10
92172-1061
Unavailable
92200
WASHER,NYLON,5.3X11.5X0.5
92200-1480
$1.59
92210
NUT,5MM
92210-0351
$5.65
130
BOLT-FLANGED,6X14
130BA0614
$1.20
132
BOLT-FLANGED-SMALL
132BB0516
$1.28
311
NUT-HEX,6MM,BLACK
311AB0600
$0.43
670
O RING,3MM
670B1503
$4.33
670A
O RING,5MM
670B1505
$3.26
