Yamaha YZF750RKC (YZF750RCA) 4LE8 1998 ELECTRICAL 2 Diagram

#

Description
Price

1

STARTER RELAY ASSY (RC19-008)

4FM-81940-02-00

Unavailable

2

BOLT, SMALL FLANGE

95027-06008-00

$7.99

3

YTX12BS YUASA BATTERY - SA

YTX-12BS0-00-00

Unavailable

4

BAND, BATTERY

4BP-82131-00-00

Unavailable

5

WIRE, PLUS LEAD

4FM-82115-00-00

Unavailable

6

WIRE, MINUS LEAD

4JH-82116-00-00

Unavailable

7

MAIN SWITCH STEERING LOCK

4NA-82501-02-00

Unavailable

8

BOLT

90109-08196-00

$8.49

9

STOP SWITCH ASSY

1KT-82530-03-00

Unavailable

10

WIRE HARNESS ASSEMBLY

4HY-82590-20-00

Unavailable

11

FUSE

2KW-82151-00-00

$6.99

12

FUSE (20A)

2GV-82151-00-00

$5.49

13

FUSE (12V 15A)

36Y-82151-00-00

$4.94

14

FUSE

4FM-82151-00-00

Unavailable

15

CLAMP(2TV)

90464-10112-00

$8.49

16

CLAMP(2TV)

90464-10112-00

$8.49

17

BAND

1UA-82591-00-00

Unavailable

18

CLAMP(4FM)

90464-15195-00

Unavailable

19

CLAMP(4FM)

90464-15195-00

Unavailable

20

CLAMP(4FM)

90464-15195-00

Unavailable

21

RELAY ASSY

3EN-81950-02-00

Unavailable

22

RELAY ASSEMBLY (3GM-00)

3GM-81950-00-00

Unavailable

23

SWITCH, SIDE STAND

4FM-82566-00-00

Unavailable

24

SCREW, PAN HEAD

98507-05014-00

Unavailable
