2002 Yamaha YZ85 (YZ85P) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 2002 Yamaha YZ85 (YZ85P), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2002 Yamaha YZ85 (YZ85P) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

KICK AXLE ASSY

5PA-15660-00-00

1
Out of stock

2

GEAR, KICK

5PA-15641-00-00

1
Out of stock

3

CLIP(4ES)

90468-23194-00

1
Out of stock

4

WASHER, PLATE(2UV)

90201-176L4-00

1
Out of stock

5

SPRING, TORSION(2UV)

90508-26750-00

1
Out of stock

6

GUIDE, SPRING

4ES-15664-00-00

1
Out of stock

7

OIL SEAL (15A)

93102-17263-00

1
Out of stock

8

GEAR, KICK IDLE

5PA-15651-00-00

1
Out of stock

9

WASHER, PLATE (10X)

90201-124F8-00

1
Out of stock

10

CIRCLIP(10Y)

99009-12400-00

1
Out of stock

11

KICK CRANK ASSY

5PA-15620-01-00

1
Out of stock

12

BOSS, KICK CRANK

5PA-15621-00-00

—
Out of stock

13

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

14

BALL (12R)

93507-32031-00

1
Out of stock

15

SCREW, COUNTERSUNK (5Y1)

90152-06010-00

1
Out of stock

16

O-RING (256)

93210-12152-00

—
Out of stock

17

PLUG, TAPER(3FA)

90336-06031-00

—
Out of stock

18

BOLT, FLANGE(4MY)

95027-06012-00

—
Out of stock

19

WASHER, PLATE

90201-06020-00

—
Out of stock
