Description

Price

1

KICK SHAFT ASSY

5TA-15601-10-00

$452.99

2

WASHER, PLATE (2K7)

90201-20685-00

$7.49

3

CIRCLIP (525)

93410-20038-00

$3.76

4

WHEEL, RATCHET

4GY-15671-00-00

$89.99

5

SPRING, COMPRESSION

90501-16016-00

$5.60

6

WASHER, PLATE(4GL)

90201-167P7-00

$9.49

7

CIRCLIP(13T)

99009-16400-00

$5.60

8

GUIDE, SPRING

5NL-15664-00-00

$13.49

9

SPRING, TORSION(2VM)

90508-30743-00

$18.99

10

WASHER, PLATE (25H)

90201-162H4-00

$9.49

11

STOPPER

5SG-15668-00-00

Unavailable

12

WASHER, LOCK

214-15686-00-00

$7.99

13

BOLT, HEXAGON

97017-06016-00

$8.49

14

OIL SEAL (22U)

93102-18278-00

$12.49

15

GEAR, KICK IDLE

5TA-15651-00-00

$127.99

16

WASHER PLATE 328171160000

90201-20276-00

Unavailable

17

CIRCLIP(1AR)

99009-20400-00

Unavailable

18

KICK CRANK ASSY

5TA-15620-01-00

Unavailable

19

BOSS, KICK CRANK

5TA-15621-01-00

Unavailable

20

SPRING COMPRESSION278156220000

90501-12081-00

Unavailable

21

BALL (12R)

93507-32031-00

Unavailable

22

SCREW, COUNTERSUNK (5Y1)

90152-06010-00

Unavailable

23

O-RING(36Y)

93210-17570-00

Unavailable

24

BOLT(2KF)

90109-085E2-00

Unavailable

25

WASHER (853)

90201-08326-00

Unavailable

Yamaha YZ450FR (YZ450F) 5TA1 2003 STARTER Diagram

KICK SHAFT ASSY

WASHER, PLATE (2K7)

CIRCLIP (525)

WHEEL, RATCHET

SPRING, COMPRESSION

WASHER, PLATE(4GL)

CIRCLIP(13T)

GUIDE, SPRING

SPRING, TORSION(2VM)

WASHER, PLATE (25H)

STOPPER

WASHER, LOCK

BOLT, HEXAGON

OIL SEAL (22U)

GEAR, KICK IDLE

WASHER PLATE 328171160000

CIRCLIP(1AR)

KICK CRANK ASSY

BOSS, KICK CRANK

SPRING COMPRESSION278156220000

BALL (12R)

SCREW, COUNTERSUNK (5Y1)

O-RING(36Y)

BOLT(2KF)

WASHER (853)
